- Air Motors and Grinding Spindles
Air Motors and Grinding Spindles
MD's air spindles and air motors work quickly and accurately when deburring, milling, grinding, drilling, brushing or polishing.
Take advantage of our no obligation motor consultation, we are there to advise you in detail on the design of new projects. We also manufacture special solutions or individual components such as planetary gears, motor blocks etc. for your air motors and spindles. We can make the correct modifications to find the solution to your application. This can be accomplished by us in small or large batch sizes in a very short time.
-
MRD 38-160 3/8''
Power0.38 kWSpeed under load160 min⁻¹Torque23.00 NmMaximum Torque43.00 NmFree speed320 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-160 3/8'' F54
Power0.38 kWSpeed under load160 min⁻¹Torque23.00 NmMaximum Torque43.00 NmFree speed320 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-160 A17
Power0.38 kWSpeed under load160 min⁻¹Torque23.00 NmMaximum Torque43.00 NmFree speed320 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-160 F54
Power0.38 kWSpeed under load160 min⁻¹Torque23.00 NmMaximum Torque43.00 NmFree speed320 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-20
Power0.38 kWSpeed under load20 min⁻¹Torque181.00 NmMaximum Torque362.00 NmFree speed40 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-25
Power0.38 kWSpeed under load25 min⁻¹Torque145.00 NmMaximum Torque290.00 NmFree speed50 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-260
Power0.38 kWSpeed under load260 min⁻¹Torque14.00 NmMaximum Torque29.00 NmFree speed520 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-260 3/8''
Power0.38 kWSpeed under load260 min⁻¹Torque14.00 NmMaximum Torque29.00 NmFree speed520 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-260 3/8'' F54
Power0.38 kWSpeed under load260 min⁻¹Torque14.00 NmMaximum Torque29.00 NmFree speed520 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-260 A17
Power0.38 kWSpeed under load260 min⁻¹Torque14.00 NmMaximum Torque29.00 NmFree speed520 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-260 F54
Power0.38 kWSpeed under load260 min⁻¹Torque14.00 NmMaximum Torque29.00 NmFree speed520 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-2600
Power0.380 kWSpeed under load2600 min⁻¹Torque1.40 NmMaximum Torque2.90 NmFree speed5200 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-2600 3/8'' F54
Power0.38 kWSpeed under load2600 min⁻¹Torque1.40 NmMaximum Torque2.90 NmFree speed5200 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-2600 F54
Power0.380 kWSpeed under load2600 min⁻¹Torque1.40 NmMaximum Torque2.90 NmFree speed5200 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-320
Power0.38 kWSpeed under load320 min⁻¹Torque12.00 NmMaximum Torque23.00 NmFree speed640 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-320 3/8''
Power0.38 kWSpeed under load320 min⁻¹Torque12.00 NmMaximum Torque23.00 NmFree speed640 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-320 3/8'' F54
Power0.38 kWSpeed under load320 min⁻¹Torque12.00 NmMaximum Torque23.00 NmFree speed640 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-320 A17
Power0.38 kWSpeed under load320 min⁻¹Torque12.00 NmMaximum Torque23.00 NmFree speed640 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-320 F54
Power0.38 kWSpeed under load320 min⁻¹Torque12.00 NmMaximum Torque23.00 NmFree speed640 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-33
Power0.38 kWSpeed under load33 min⁻¹Torque110.00 NmMaximum Torque220.00 NmFree speed66 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-33 F100
Power0.38 kWSpeed under load33 min⁻¹Torque110.00 NmMaximum Torque220.00 NmFree speed66 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-40 F100
Power0.38 kWSpeed under load40 min⁻¹Torque90.00 NmMaximum Torque180.00 NmFree speed80 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-55
Power0.38 kWSpeed under load55 min⁻¹Torque66.00 NmMaximum Torque132.00 NmFree speed110 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-55 F100
Power0.38 kWSpeed under load55 min⁻¹Torque66.00 NmMaximum Torque132.00 NmFree speed110 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-580
Power0.38 kWSpeed under load580 min⁻¹Torque6.40 NmMaximum Torque13.00 NmFree speed1160 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-580 3/8''
Power0.38 kWSpeed under load580 min⁻¹Torque6.40 NmMaximum Torque13.00 NmFree speed1160 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-580 3/8'' F54
Power0.38 kWSpeed under load580 min⁻¹Torque6.40 NmMaximum Torque13.00 NmFree speed1160 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-580 A17
Power0.38 kWSpeed under load580 min⁻¹Torque6.40 NmMaximum Torque13.00 NmFree speed1160 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-580 F54
Power0.38 kWSpeed under load580 min⁻¹Torque6.40 NmMaximum Torque13.00 NmFree speed1160 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-70
Power0.38 kWSpeed under load70 min⁻¹Torque52.00 NmMaximum Torque103.00 NmFree speed140 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-70 F100
Power0.38 kWSpeed under load70 min⁻¹Torque52.00 NmMaximum Torque103.00 NmFree speed140 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-9400
Power0.38 kWSpeed under load9400 min⁻¹Torque0.40 NmMaximum Torque0.80 NmFree speed18800 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 38-9400 F54
Power0.38 kWSpeed under load9400 min⁻¹Torque0.40 NmMaximum Torque0.80 NmFree speed18800 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 55-105
Power0.62 kWSpeed under load105 min⁻¹Torque56.00 NmMaximum Torque112.00 NmFree speed210 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 55-105 F100
Power0.62 kWSpeed under load105 min⁻¹Torque56.00 NmMaximum Torque112.00 NmFree speed210 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 55-11000
Power0.62 kWSpeed under load11000 min⁻¹Torque0.54 NmMaximum Torque1.10 NmFree speed22000 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 55-11000 F77
Power0.62 kWSpeed under load11000 min⁻¹Torque0.54 NmMaximum Torque1.10 NmFree speed22000 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 55-16
Power0.62 kWSpeed under load16 min⁻¹Torque370.00 NmMaximum Torque740.00 NmFree speed32 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 55-1800
Power0.62 kWSpeed under load1800 min⁻¹Torque3.30 NmMaximum Torque6.60 NmFree speed3600 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 55-1800 F77
Power0.62 kWSpeed under load1800 min⁻¹Torque3.30 NmMaximum Torque6.60 NmFree speed3600 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 55-2200
Power0.62 kWSpeed under load2200 min⁻¹Torque2.70 NmMaximum Torque5.40 NmFree speed4400 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 55-2200 F77
Power0.62 kWSpeed under load2200 min⁻¹Torque2.70 NmMaximum Torque5.40 NmFree speed4400 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 55-25
Power0.62 kWSpeed under load25 min⁻¹Torque236.00 NmMaximum Torque472.00 NmFree speed50 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 55-250
Power0.62 kWSpeed under load250 min⁻¹Torque24.00 NmMaximum Torque47.00 NmFree speed500 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 55-250 F77
Power0.62 kWSpeed under load250 min⁻¹Torque24.00 NmMaximum Torque47.00 NmFree speed500 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 55-2800
Power0.62 kWSpeed under load2800 min⁻¹Torque2.10 NmMaximum Torque4.20 NmFree speed5600 min⁻¹Direction of rotationclockwise4 weeks -
MRD 55-2800 F77
Power0.62 kWSpeed under load2800 min⁻¹Torque2.10 NmMaximum Torque4.20 NmFree speed5600 min⁻¹Direction of rotationclockwise4 weeks -
MRD 55-300
Power0.62 kWSpeed under load300 min⁻¹Torque20.00 NmMaximum Torque39.00 NmFree speed600 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 55-300 F77
Power0.62 kWSpeed under load300 min⁻¹Torque20.00 NmMaximum Torque39.00 NmFree speed600 min⁻¹Direction of rotationclockwiseResistant to stalling< 10 items -
MRD 55-400
Power0.62 kWSpeed under load400 min⁻¹Torque15.00 NmMaximum Torque30.00 NmFree speed800 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 55-400 F77
Power0.62 kWSpeed under load400 min⁻¹Torque15.00 NmMaximum Torque30.00 NmFree speed800 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 55-50
Power0.62 kWSpeed under load50 min⁻¹Torque118.00 NmMaximum Torque236.00 NmFree speed100 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 55-50 F100
Power0.62 kWSpeed under load50 min⁻¹Torque118.00 NmMaximum Torque236.00 NmFree speed100 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks -
MRD 55-500
Power0.62 kWSpeed under load500 min⁻¹Torque12.00 NmMaximum Torque24.00 NmFree speed1000 min⁻¹Direction of rotationclockwiseResistant to stalling4 weeks
